QULOOS MUB5 R2R Portable DAC/AMP
Description
The QULOOS MUB5 is a high‑end R2R (resistor ladder) portable DAC and headphone amplifier, designed for audiophiles seeking precision, transparency, and portability. It features top-tier engineering, premium components, and a refined sound signature.
Quloos has engineered a precision 19+5 segmented R2R DAC architecture featuring resistors matched to 0.01% tolerance. The MUB5 integrates 178 resistors forming the complete R2R network for detailed, high-resolution audio processing.
Its design combines a pristine, rich R2R DAC system with a powerful discrete amplifier and a clean NDCS shielded power supply composed of 20 independent circuits, an LTC6655 voltage reference, and QA661 low-jitter crystal oscillators. Elevate your portable audio setup with the Quloos MUB5 and experience uncompromised high-fidelity sound quality.
Pure R2R DAC Architecture:-
The QULOOS MUB5 employs a 19+5 segmented R2R DAC design incorporating 178 precision-matched resistors with a tolerance of 0.01%. This carefully engineered R2R configuration ensures detailed, high-resolution audio processing and produces a rich, musical sound with exceptional accuracy and pristine high-fidelity performance.
Customize Your Sound With Two Filter Options:-
The QULOOS MUB5 offers two filter settings: custom Oversampling (OS) and No-Oversampling (NOS/M1). The OS mode produces an accurate, wide, and detailed sonic response, while the NOS mode delivers a more laid-back sound character. In NOS mode, the MUB5 reproduces the audio exactly as recorded, without adding any coloration.
Fully Discrete High-Power Amplification:-
The QULOOS MUB5 features a fully discrete headphone amplification stage utilizing FZT power transistors alongside OPA627 chips in the buffer section. It delivers a robust output power of up to 1.5W on battery and up to 2.5W per channel when powered via 12V DC input. This strong output allows the MUB5 to effortlessly drive a wide range of IEMs and headphones, performing exceptionally well even with demanding models.
Multiple Input, Output Options:-
The QULOOS MUB5 is a premium portable DAC/AMP offering extensive input and output versatility to suit varied audio setups. It supports USB, coaxial, optical, and Bluetooth inputs, providing flexible connectivity options. Equipped with both 3.5mm and 4.4mm headphone jacks along with line-out capability, the MUB5 functions effectively as both a headphone amplifier and an adjustable preamplifier.
Clean Power Delivery with Properly Shielded Power Supply Design:-
The QULOOS MUB5 delivers purified power to every circuit element. It incorporates a custom NDCS shielded power supply featuring 20 separate power circuits, an LTC6655 voltage reference chip, and QA661 crystal oscillators. This meticulously engineered power system ensures exceptionally clean audio performance without detectable power supply noise. The device offers approximately 7 to 8 hours of battery life and is compatible with QC fast charging for efficient recharging.
Key Features
- R2R / resistor ladder DAC architecture for natural, detailed audio
- Supports high-resolution audio playback with excellent dynamic range
- Compact and portable: ideal for on‑the‑go listening
- Premium finishing: offered in Titanium (Ti) and Ti‑Gold color variants
- Comprehensive accessory kit included:
- MUB5 unit
- Leather case
- USB‑C to USB‑C cable
- USB‑A to USB‑C cable
- Charging cable
- User manual
- Screen protectors (×2)
