Ideon Audio Ayazi mk2 DAC

Name: Ideon Audio Ayazi mk2 DAC
Brand: Ideon
Price: 4200.0 USD
Availability: InStock

$4,200.00

Quantity:

The jack of all trades

The Ayazi mk2 DAC is expertly engineered to unlock the musical essence contained within digital data. It delivers sound with an impressively wide dynamic range, minimal distortion, and low noise, ensuring precise imaging and seamless musical flow. Tested across a variety of high-end audio systems, this versatile DAC excels as a reliable and adaptable digital-to-analog converter for any listening environment.

A high-performance DAC

Built with straightforward, robust design, the Ayazi has been praised by reviewers as potentially outperforming DACs that cost twice as much. It achieves the original goal: delivering the true musical experience with sound quality that is astonishing for its price. Combining form and function within an accessible budget, the Ayazi stands as the affordable benchmark in DAC performance.

Input Protection

The USB input comprises Ideon Audio’s proprietary electrostatic protection circuit; the best way to fight against signal degradation and noise is to keep it at bay before it enters the signal!

Asynchronous Dual Clock Input

Pushing jitter and the noise floor to vanishingly low levels to achieve phase-correct sound, and dynamics.

Femto clock architecture.

Pushes jitter and noise floor below perceptible levels in our circuit. Two high quality CCHD-957 oscillators by Crystek.

Over Engineered, Over the Top Power

The Ayazi mk2 DAC demands not just ample power, but exceptionally clean power free from high-frequency noise, electrical interference, and distortion that can degrade performance. By employing premium regulators, high-end audiophile capacitors, and discrete, ultra-stabilized power supplies, it effectively minimizes unwanted electrical and digital noise. This meticulous power design delivers unmatched dynamic range and clarity within its category, establishing the Ayazi as a standout sonic performer.

DIGITAL INPUTS	USB type 2 and above, SPDI/F
OUTPUT FULL SCALE	2.0V RMS
FREQUENCY RESPONSE	10Hz-25kHz (+/- 0.5dB)
SNR (DC to 20kHz)	>112dB
CROSSTALK	-110dB
SNR (A WEIGHTED 20HZ-20KHZ)	>130dB on all outputs
THD+N (1kHz FS 96 kS/s)	<0.002%E
USB INPUT	Transfer mode: Asynchronous (dual clock) Device class: Type 2 or above Bit depth: 32 bit Sampling rates: 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz
DIMENSIONS (W X H X D)	36cm X 17cm X 8cm
SPDIF / COAXIAL INPUT	Bit depth: 24 bit Sampling rates: 44.1, 48, 96, 192 kHz
CONTROLS	On/off switch, led indicator USB / SPDI/F input, sync led indicator
POWER REQUIREMENTS	230 / 110 V AC, 1A, 20W max
OPERATING TEMPERATURE	0-35˚ C
RELATIVE HUMIDITY	5-95% non-condensing
OUTPUT	Stereo unbalanced impedance: 250 Ω
