Astel&Kern SP3000M
Compact Size, Limitless Sound
The A&ultima series continues to present advanced and innovative technology and the standard of perfect sound.
We renewed our commitment to this goal and began to delve deep into the concept of true portability with unrivaled performance and unmatched sound performance.
The process was not easy; we had to overcome numerous unending challenges in keeping the perfect sound performance on par with SP3000 while reducing the device’s size. We began the development of an audio device that is smaller and lighter, while still delivering perfect sound. After dozens of changes were made to the circuit, we finally present you with the SP3000M.
The innovative Hexa audio structure separates digital and analog signal processing and independent dual audio circuit for unrivaled audio performance SP3000M offers all these features in its lighter, compact design allowing you to enjoy incredibly vivid sounds you will not experience anywhere else.
A true Hi-Fi portable audio player with the best audio performance and equally sophisticated design, the SP3000M offers all of this in the palm of your hand.
- The successor to the SP3000’s global, top-notch audio performance
- Lightweight and portable, anywhere and at any time
- TERATON ALPHA Sound Solution, the essence of AK’s audio technology
- Complete Separation of Digital and Analog Signals in a HEXA Structure
- Equipped with proven independent dual audio circuits
- High-performance Qualcomm Snapdragon 6125 CPU
- Analog Sensitivity VU Meter
-
AK4499EX
Quad-DAC -
Octa-Core
Snapdragon -
TERATON
ALPHA -
VU METER
-
aptX™-HD
LDAC -
NATIVE
DSD 512
SP3000M
The “M” in SP3000M represents the diverse features that we offer in the player.
-
Mini
Smaller in size than SP3000
-
Mobility
Even better portability
-
Maximum
The product with the best audio performance
-
Mania
A product for those with a passion for the vivid sounds that SP3000M provides
-
Mate
A companion with you anywhere and at anytime
-
Moment
Adding sentiment to life's mundane moments
SP3000M vs SP3000
- CPU Qualcomm 6125 Octa-Core Qualcomm 6125 Octa-Core
- DAC AK4191EQ x2 & AK4499 x4 AK4191EQ x2 & AK4499 x4
- Display 4.1” 720 x 1280 5.5” 1080 x 1920
- DAR Support (384kHz / DSD64) Support (384kHz / DSD256)
- Audio Output 3.5mm, 4.4mm 2.5mm, 3.5mm(SPDIF), 4.4mm
- SNR 130dB 130dB
- THD+N 0.0003% @ 1kHz 0.0004% @ 1kHz
- Battery 4,200mAh (about 10hrs) 5,050mAh(about 10hrs)
- Material Aluminum Stainless Steel 904L
- Weight 237g 493g
- Wheel LED X O
* Audio Spec is based on Balanced
Complete Separation of Digital and Analog Signals in a HEXA Structure
We equipped the SP3000M with the same innovative Hexa audio circuit design first found in the SP3000, that has four of AKM’s flagship AK4499EX DACs and two separate AK4191EQ chips that handle digital signals. Thanks to this technology, you can enjoy amazingly vivid sounds only Astell&Kern can create.
Most digital players process digital and analog signals together inside the DAC. However, the SP3000’s advanced HEXA structure reduces the noise of the digital signal input through the AK4191EQ, a separate digital delta-sigma modulator, and the AK4499EX DAC is then designed to process the analog signals separately.
With such an unparalleled design, SP3000M physically separates digital and analog signals, completely boasting the perfect A&ultima sounds through the unmatched 130 dB SNR, equal to the SP3000, despite its much smaller size.
Silver Plated Shield Can
A shield can is applied to prevent various noise and electromagnetic interference from affecting the audio block.
The SP3000M takes it a step further to achieve excellent audio performance and perfect shielding by applying highly conductive, high-purity silver on the existing shield can, and physically separating digital and analog signals.
Stunning Audio Performance with Independent Dual Audio Circuits
In order to create a truly innovative DAP, not just a great DAP, we tried to overcome the limitations of sound by envisioning an independent dual audio circuit that has never been attempted by anyone featuring a HEXA structure with unbalanced and balanced outputs.
Almost all other DAPs, including Astell&Kern, use an internal DAC for both unbalanced and balanced outputs. Since the signal from the DAC is divided into unbalanced and balanced then delivered to the AMP, an Audio Switch is essential. However, when using a switch, there is a limit to the range that can receive the signal sent by the DAC, so most DAPs reduce the signal size first and then when the signal is transmitted back to the amplifier, it is necessary to restore the original signal size. This causes a limitation in improving the audio performance.
To overcome the limitations, our engineers designed a HEXA structure using two AK4191EQs and four AK4499EXs, creating an innovative unbalanced and balanced independent dual audio circuit design. As a result, the SP3000M achieves a SNR of 130dB, the best of any DAP available. You can feel the clean, pure delicacy of sound with the SP3000M that you can't experience in any other DAP.
- SNR 130dB 130dB 122dB 128dB 125dB
* SP3000M and SP3000 are based on the condition no-load, Balanced, and there may be differences depending on the measurement method.
* Third-party models are the specifications listed on the official website.
SP3000M HEXA-Audio Circuitry structure
TERATON ALPHA, The Essence of A&K Audio
Technologies Merged Into the SP3000M
In order to develop the ultimate audio player that has never been experienced before, not only do we use the latest DAC and technology available, but we use the innovative audio technology of TERATON ALPHA, AK's Ultimate Sound Solution.
TERATON ALPHA, engineered through endless research, is Astell&Kern's unique technology that has been designed to produce audio playback that is close to the original sound through effective power noise removal, efficient power management and unwavering amplification, and a fully converted audio output interface. HEXA-Audio Circuitry structure and independent dual audio circuit implemented to the SP3000 was completed with TERATON ALPHA's sound solution, to create the purest original sound, and was inherited to the SP3000M.
Drive Your Music,
Latest Snapdragon Octa-Core CPU
A&ultima SP3000M is equipped with a Snapdragon 6125 Octa-core processor, so you can enjoy the overwhelming sound, with faster system response and a redesigned generation user interface that moves comfortably and smoothly.
Featuring a high-performance CPU and improved 8GB of DDR4 memory, which is twice the amount commonly used in other digital audio players, the more powerful system is stable with fast and fluid movement.
The CPU, memory and wireless communication parts are configured as one module, with the digital circuit parts arranged in the same area creating a single system on a chip (SoC). This maximizes the efficiency of the overall circuit configuration by providing more dedicated audio-only circuit space as well as reducing heat and noise from digital circuits.
SP3000M comes with a VU Meter GUI, which debuted on the SP3000T and was well-received by consumers for an even more immersive experience.
The VU Meter, an iconic piece of audio equipment with a long-standing history, displays voltage levels of voice signals to aid volume measurement and adjustment.
Beyond its utilitarian function, the VU Meter's unique design and retro charm help to enhance the immersive music-listening experience.
Conveniently accessible via the bottom navigation bar, the VU Meter on the SP3000M allows you to monitor sound levels while viewing album art or streaming via our Open App Service.
Digital Audio Remaster Technology for Even More Vivid Original Sound
The SP3000M is equipped with Digital Audio Remaster(DAR) technology, which was developed to deliver fine sound at higher sample rates.
DAR technology is developed to upsample the sample rate of the sound source being played to go beyond the limits of the source format.
The high sample rate allows more refined play and offers delicate and analog-like original sound,
helping you to enjoy the richness of the original sound, subtle differences in the nuance of the music and rich sounds at a higher level.
-
PCM 44.1kHz range PCM will be converted to 352.8kHz for playback
48kHz range PCM will be converted to 384kHz for playback
No conversion will be made when playing DSD with this option selected - DSD Converts PCM of 192kHz or lower to DSD64
* The DAR function can be turned on and off and you may select it to suit the source sound and your own preferences.
* Max PCM rate 384kHz/DSD64 conversion play is supported, and the files will be converted to and played in the sample rates that fit the source sound.
Sound Design With DAC Filters
With the SP3000M, you can have fun creating your own sound style by selecting various DAC filters provided by the DAC manufacturer.
Design your own sound with 6 different DAC filters.
-
Natural Tone Super Slow Roll-off No echo reproduces
natural sound Ultra-Sharp -
Acoustic Tone Short Delay Slow Roll-off Minimal echo reproduces
original sound Sharp -
Traditional Tone Slow Roll-off Minimal echo reproduces
original sound Middle -
Harmonic Sound Low dispersion Short echo reproduces
original sound Middle -
Acoustic Sound Short Delay Sharp Roll-off Post echo enhances
bass sound Sharp -
Traditional Sound Sharp Roll-off Pre and post echoes make
powerful sound Slow
Astell&Kern's audio players are seamlessly integrated with external streaming apps through the Open App Service. Enjoy high-quality streaming from platforms like Tidal and Apple Music with the unparalleled fidelity of the SP3000M.
With AK Connect, our network play feature, you can easily access and play/download music from PCs and devices connected to the same network as the SP3000M
in real-time.
Elevate your streaming experience to new heights with Open App Service and AK Connect.
BT Sink allows you to connect the SP3000M to external devices such as smartphones and PCs via Bluetooth.
Transmit sound from an external device directly to the SP3000M with just one pairing. Enjoy superior sound quality with support for high-quality codecs such as LDAC and AptX. Elevate your listening experience with seamless wireless connectivity through BT Sink.
Crossfeed,
Speaker effect when listening through headphones
In a headphone environment in which the left and right channels are clearly separated, ear fatigue may increase during prolonged listening.
The moment you turn on Crossfeed, the experience of crisp, but comfortable sound begins.
Crossfeed mixes parts of the original signal from one channel and sends that signal to the opposite channel with a time difference to center the sound image.
Through the use of detailed settings such as Shelf Cutoff, Shelf Gain, and Mixer Level,
you can set the level of crossfeed according to your listening preferences.
* Crossfeed supports PCM formats of 24 bits / 192 kHz or less.
Supports Native DSD512, 32bit/768kHz
SP3000M supports Native DSD512 and up to 32bit/768kHz with Astell&Kern’s excellent audio technology, allowing you to fully enjoy your favorite music.
QC 3.0 Fast Charging Supported
The SP3000M supports Qualcomm QC 3.0 fast charging, so you can charge your DAP faster and more efficiently than previous models, reaching a full charge in about 3.5 hours.
AK File Drop to enjoy wireless transfers
The new AK File Drop function in the SP3000M makes files transfers easier and more convenient. Using AK File Drop, you can freely transfer files wirelessly through a PC, smartphone, or FTP program located on the same network. Music file management is now possible with a cableless, wireless solution.
ReplayGain Automatically and Uniformly Adjusts Playback Volume
ReplayGain, which adjusts sound sources with different volumes to an identical level, has been applied. Now, enjoy your own playlists seamlessly through the ReplayGain feature on SP3000M.
* ReplayGain supports up to 24-bit/192 kHz sound sources.
Dual-band Wi-Fi (2.4/5 GHz)
SP3000M offers Dual Band Wi-Fi (2.4/5 Ghz), providing enhanced network performance to enjoy Hi-Fi music through various streaming services.
-
MQA (Master Quality Authenticated) is an award-winning British technology that delivers the sound of the original master recording.
Discover more
The master MQA file is fully authenticated and is small enough to stream or download. Visit mqa.co.uk for more information.
Astell&Kern SP3000M includes MQA technology, which enables you to play back MQA audio files and streams,
delivering the sound of the original master recording.
The MQA logo is a trade mark of MQA Limited. © MQA Limited 2018 -
Qualcomm aptX is a product of Qualcomm Technologies, Inc. and/or its subsidiaries.
Discover more
Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other countries.
aptX is a trademark of Qualcomm Technologies International, Ltd., registered in the United States and other countries. -
LDAC and LDAC logo are trademarks of Sony Corporation.
Discover more -
Roon Ready network players from our partners have Roon’s high-resolution streaming technology built right in.
Discover more
They combine simple setup, daily reliability, and support for the highest level of digital audio performance in the industry.
Every Roon Ready player is certified by Roon to guarantee the same stellar experience, regardless of its manufacturer, its price, or its features.
Premium Leather Case
The SP3000M’s bundle case is crafted from soft cowhide by GRUPPO MASTROTTO, boasting a superior level of craftsmanship that befits the A&ultima SP3000M.
The leather case features a soft touch and has undergone a proprietary patented "anti-bacterial" and "anti-virus" process.
Using chrome tanning and dyeing with high-quality pigments, the leather maintains a uniform surface quality and showcases the distinctive vibrant colors characteristic of Italian leather. The rear pattern of the case expresses the same pattern as the SP3000M, providing a perfect sense of unity.
GRUPPO MASTROTTO is a leather specialist manufacturer that continues a tradition of over 60 years since the Mastrotto family established 'Conceria Mastrotto' in Arzignano, Italy, in 1958. With more than 2,200 employees worldwide, they produce high-quality leather through 18 rigorous processes across 15 factories. They are one of Italy's most authoritative groups in the leather industry.
DESIGN
The design concept of SP3000M is “Tension.”
While keeping the diamond-shaped front of SP3000, we added new features to emphasize it as one of our flagship models.
The design of SP3000M was inspired by a diamond ring’s diamond and its prong. Like the dramatic melodies of music, we added tension to the alignment of the volume knob and protector. The volume wheel knob meets the protector at the top and bottom ends, creating an image of the wheel being held with tight tension.
We also placed triangular shapes growing smaller toward the wheel, maximizing a sense of tension focusing on the wheel.
The design of SP3000M brings a rhythmic tension from its edges and guides your focus to the volume wheel knob. Other design details include the cross patterns etched on the glass surface at the back. Reminiscent of the SP3000’s design, it also adds SP3000M’s unique concept of “Tension” in the two patterns meeting at the corners.
General Specifications
* Model SP3000M
* Body Color Black
* Body Material Aluminum
* Display 4.1inch HD 720 x 1280 touch screen
* Supported Audio Formats WAV, FLAC, WMA, MP3, OGG, APE, AAC, ALAC, AIFF, DFF, DSF
* Sample rate PCM : 8kHz ~ 768kHz (8/16/24/32bits per Sample)
DSD : DSD64(1bit 2.8MHz), Stereo / DSD128(1bit 5.6MHz), Stereo / DSD256(1bit 11.2MHz), Stereo
DSD512(1bit, 22.4MHz), Stereo
* Output Level Unbalanced 3.3Vrms │ Balanced 6.3Vrms (Condition No Load)
* CPU Octa-core
* DAC AKM AK4191EQ x2 & AK4499EX x4
* Decoding Support up to 32bit / 768kHz playback
* Input USB Type-C input (for charging & PC & MAC)
* Outputs Unbalanced Out (3.5mm), Balanced Out 4.4m (only 5-pole supported)
* Wi-Fi 802.11 a/b/g/n/ac (2.4/5GHz)
* Bluetooth V5.0 (A2DP, AVRCP, Qualcomm® aptX™ HD, LDAC, LHDC)
* Dimensions 2.72” (69.1mm)[W] x 4.70” (119.6mm)[H] x 0.74” (18.8mm)[D]
* Weight Aluminum about 8.36oz (237g)
* Feature Enhancements Firmware upgrade supported (OTA)
* Operating Temperature 0℃ ~ + 40℃ (32℉~ 104℉)
Audio Specifications
* Frequency Response ±0.020dB (Condition : 20Hz~20kHz) Unbalanced │ ±0.025dB (Condition : 20Hz~20kHz) Balanced
±0.032dB (Condition : 20Hz~70kHz) Unbalanced │ ±0.025dB (Condition : 20Hz~70kHz) Balanced
* S/N 126dB @ 1kHz, Unbalanced │ 130dB @ 1kHz, Balanced
* Crosstalk -140dB @ 1kHz, Unbalanced │ -144dB @ 1kHz, Balanced
* THD+N 0.0005% @ 1kHz, Unbalanced │ 0.0003% @ 1kHz, Balanced
* IMD SMPTE 0.0004% 800Hz 10kHz (4:1) Unbalanced │Balanced
* Output Impedance Unbalanced Out 3.5mm (0.6ohm) │ Balanced Out 4.4mm(1.2ohm)
Clock Source
* Clock Jitter 25pS (Typ)
* Reference Clock Jitter 200 Femto Seconds
Storage Capacity
* Built-in Memory 256GB [NAND]
* External Memory microSD x1 (Max. 1.5TB)
Battery
* Capacity 4,200mAh 3.8V Li-Polymer
* Charge Time about 3.5hours (QC3.0 Charging)
* Playback Time about 10hours (Standard : FLAC, 16bit, 44.1kHz, Vol.80, LCD Off)
